SCHELL Exposed shower faucet. VITUS VD-C-T CVD-Timed,therm.,man.TD acc.to DVGW

Surface-mounted Shower Faucet VITUS VD-C-T / u

\n

Mixed water, ThermoProtect thermostat

Triggered by CVD-Touch electronics with automatic closing process. Battery operated. Shower connection at the bottom. Suitable for networking with SCHELL water management system SWS. Configurable via SCHELL Single Control SSC. \n

\n

\n

Scope of delivery

\n

\n
• Electronic self-closing surface-mounted shower faucet
\n
\n
• ThermoProtect thermostat according to EN 1111, unlockable/lockable temperature stop 38 °C, scald protection in case of cold water supply failure
\n
• CVD-Touch electronics, programmable, splash and jet water protected IP65
\n
• Solenoid valve 6 V with pre-filter
\n
• Valve for manual thermal disinfection (according to DVGW worksheet W 551)
\n
• 2 backflow preventers RV (EN 1717: EB)
\n
• Battery compartment 6 V (integrated)
\n
\n
• 4x AA alkaline batteries 1.5 V
\n
• 2 S-connections and rosettes (depth-adjustable)
\n

\n

Technical data

\n

\n
• Settings via SWS/SSC
\n
\n
• Actuation force (light / medium / heavy)
\n
• Manual programming (Off / On)
\n
• Max. run time (1 - 950 s)
\n
• Stagnation flush (Off / 1 - 1000 s, every 1 - 250 h after last flush / every 1 - 250 h)
\n
• Actuation lock time (Off / 1 - 255 s, Timeout 1 - 2000 min)
\n
\n
• Settings via manual programming
\n
\n
• Max. run time (4 - 120 s, 10 program levels)
\n
• Stagnation flush (Off / 20 s, every 24 h)
\n
\n
• Flow pressure: 1.0 - 5.0 bar
\n
• Max. static pressure: 8 bar
\n
• Max. operating temperature: 70 °C (80 °C for thermal disinfection)
\n
• Material: Housing brass compliant with TrinkwV
\n
• Surface: chrome
\n
• Connection: 2x DN 15 G 1/2 AG
\n
• Outlet: DN 15 G 1/2 AG (bottom)
\n
• Certificates: PA-IX 28574/IB, Belgaqua
\n
• Noise class: I
\n
• Flow class: B
