SCHELL Self-closing Washbasin Tap XERIS SC HD-M S small, chrome

Self-closing basin tap XERIS SC

\n

HD-M small - high-pressure mixed water

Manual activation with automatic closing. Easy run time adjustment. \n

\n

\n

Scope of delivery

\n

\n
• Self-closing single-hole tap
\n
\n
• Self-closing cartridge SC II with hot water limitation
\n
• Aerator
\n
\n
• 2 flexible connection hoses Clean-Fix S G 3/8 IG x 380 mm, with integrated backflow preventer (RV, EN 1717: EB) and pre-filter
\n
• Mounting material for washbasin installation
\n

\n

Technical data

\n

\n
• Run time: 2 - 15 s adjustable (7 s factory setting)
\n
• Flow rate: max. 5 l/min pressure-independent
\n
• Flow pressure: 1.0 - 5.0 bar
\n
• Max. static pressure: 8 bar
\n
• Max. operating temperature: 70 °C (80 °C for thermal disinfection)
\n
• Material: Brass housing compliant with TrinkwV (German Drinking Water Ordinance)
\n
• Surface: chrome
\n
• Connection: 2x G 3/8 IG
\n
• Certificates: PA-IX 29071/IO, Belgaqua
\n
• Noise class: I
\n
• Flow class: O
