SCHELL Combination Angle Valve 3/8 chrome COMFORT with NRV with SR

Combination Angle Valve COMFORT

\n
With COMFORT handle and grease chamber upper part. Backflow prevention HD (EN 1717). \n

\n

\n

Scope of delivery

\n

\n
• Combination angle valve
\n
\n
• 2 COMFORT handles
\n
• Backflow preventer RV (EN 1717: EB) in appliance connection outlet
\n
• Pipe aerator RB (EN 1717: HB) in appliance connection outlet
\n
• ASAG easy (self-sealing connection thread)
\n
• Grease chamber upper part
\n
• Long push shaft
\n
\n
• Hose screw connection
\n
• Tensile brass cone compression fitting with length compensation
\n
• Push rosette Ø 54 mm
\n

\n

Technical data

\n

\n
• Material: Brass compliant with German Drinking Water Ordinance
\n
• Surface: chrome
\n
• Connection: DN 10 G 3/8 male thread with ASAG easy
\n
• Outlet: Ø 10 mm (DN 10 G 3/8 male thread), hose screw connection Ø 14.5 mm (DN 20 G 3/4 male thread)
\n
• Backflow prevention device according to EN 1717: HD
\n
• Certificates: PA-IX 026/IIA, DIN-DVGW applied for, ACS, Belgaqua
\n
• Noise class: II, at 100% flow
\n
• Flow class: A
\n
