Resideo PrimusPlus Filter Combination 100 microns, lead-free, threaded fitting, 1

Resideo Primus-Plus Filter Combination
The FK74CS filter combination integrates a backwashable fine filter and pressure reducer in one device. It continuously ensures the water supply with filtered drinking water at the pressure set for the respective drinking water installation.
The fine filter prevents the ingress of foreign particles, such as rust particles, hemp residues and sand grains, thus reducing the probability of corrosion and ensuring hygienically pure drinking water. The pressure reducer prevents pressure damage and reduces energy and drinking water consumption.
The filter combinations are particularly suitable for installation in drinking water installations where a pressure reducer is required. Installation in horizontal and vertical pipelines is possible.

Features:
• Lead-free: Lead content of all materials less than 0.1%
• Integrated pressure reducer with balanced single seat valve
• Inlet pressure compensation - fluctuating inlet pressure has no influence on the outlet pressure and thus on the use of the drinking water installation
• Filtered water supply even during backwashing
• Backwash system for fast and thorough cleaning of the filter with low water consumption
• Automatic backwash system can be retrofitted with ISO flange connection
• Impact-resistant plastic filter bowl allows easy visual inspection of filter contamination
• Filter insert and complete filter bowl replaceable
• ACS certified
• All materials according to UBA KTW
• Certified as low-noise by TÜV LGA, Group 1 without restrictions
• 5-year warranty
Medium: Drinking water
Medium temperature: 2 °C - 30 °C
Pressure rating item: PN 16
Housing material: Brass, lead-free
Filter bowl material: Polyamide (PA)
Filter fineness: 100 my
Nominal size: 1
