Pallet racking H5500xW2700xD1100mm starter bay, bay load 4260kg META

Longitudinal or transverse storage possible · Beams with 4-hook claw adjustable in height in 50 mm increments · Closed box sections for high stability · Bolted uprights made of cold-formed sections · Uprights galvanized · Beams powder-coated red-orange, RAL 2001 · Overall width, basic shelving unit = beam length + 170 mm, add-on shelving unit = beam length + 85 mm, overall depth = frame depth · Shelf loads apply with uniform load distribution · Additional shelf levels are possible up to the max. bay load · The specified bay loads apply to shelving units with at least 4 bays · In accordance with Professional Association UVV BGR234, permanent factory inspection according to DIN ISO 9001 Further technical properties: · Pallet weight: 470kg · Beam type: 85/15 · Subject to inspection: yes Scope of delivery: Basic shelving unit 2 uprights incl. floor anchors, beam type according to table Add-on shelving unit 1 upright incl. floor anchors, beam type according to table If there are fewer than 4 shelving bays next to each other, the load values for beams and upright frames are reduced: 1 shelving bay - to 80% 2 shelving bays - to 87% each 3 shelving bays - to 93% each from 4 shelving bays - 100%
