OVENTROP Str. Shut-off valve HydroCom A PN16 DN25, Rp1 IG, HydroPort, EZB

For shutting off distribution pipes in central heating and cooling systems with closed circuits. Angled seat valve without presetting. A HydroPort auxiliary valve on the outlet side for connecting the impulse line of a differential pressure control valve. Maintenance-free stem seal. Main function: Isolation valve Medium: Water, water-glycol mixture Pressure rating: PN 16 Nominal diameter: DN 25 Connections: Internal thread Connection size: Rp 1 Kvs: 5.9 Operating temperature: -20 - 120 C Can be isolated: Yes Drainage: with HydroPort adapter Impulse line connection: Yes, via HydroPort Housing material: Dezincification-resistant brass Design: Angled seat Installation location: Flow or return Insulation shell: available as an accessory Item no.: 1062728 EAN: 4026755480368 Manufacturer: Oventrop GmbH &, Co. KG Subject to technical changes
