MIG/MAG Welding System WT-PULS 250iSyn 25-250 A gas-cooled WELDING TEAM

compact MIG/MAG pulse system for almost spatter-free welding of steel, stainless steel, aluminum and for MIG brazing · based on state-of-the-art inverter technology, continuously adjustable · complete database of all welding parameters and characteristics, for both pulse and normal MIG/MAG welding · large LCD display · MULTIPULSE: a second, superimposed pulse frequency can be used to specifically apply ripples for visible seams · adjustable hot arc prevents lack of fusion at the start of welding · 4-roll drive · 2-stroke, 4-stroke modeFurther technical features:· Width: 470mm· Length: 760mm· Welding current at 35% ED/40° C: 220A· Operating modes: 2-stroke / 4-stroke· Drive: 4-roll· Wire Ø: 0.6-1.2mm· Weight: 45kg· Mobility: mobile· Protection class: IP21· Wire spool: S 200/B 300· Maximum current: 250A· Design: compact· Height: 760mm· Welding process: MIG/MAG + MIG/MAG Pulse· Wire feed: automatic· Mains voltage: 400 V / 50/60 Hz· Fusing: 16A· Power consumption: 8.5kVA· Open circuit voltage: 75V
