KALDEWEI Shower Tray SUPERPLAN CLASSIC 90x120 alpine white

KALDEWEI SUPERPLAN CLASSIC Shower Surface, 900x1200x32 mm, Model No: 406-1

Product description:
Floor-level shower surface with corner waste and all-round embossing.

EU TAXONOMY READY thanks to the official publication of EPDs

Here you can find the current Environmental Product Declaration (EPD):
https://www.kaldewei.de/unternehmen/nachhaltigkeit/epd

Steel enamel products stand for sustainability and are 100% circular.

The standard white variant of this product
is officially Cradle to Cradle certified® in Silver.

Model: SUPERPLAN CLASSIC
Model No: 406-1
Overall length (mm): 900
Overall width (mm): 1200
Rim height (mm): 32
Depth (mm): 25
Material: KALDEWEI Steel Enamel
Manufacturer: KALDEWEI

Product specification:
Shower surface shape: Rectangular
Installation: Suitable for floor-level installation
Warranty: 30 years according to warranty certificate
MADE IN GERMANY
Waste hole (mm): 90
Waste position: Corner waste
Earthing lug for potential equalisation.
Weight (kg): 28.40
CO2 footprint (kg): 36.18

OPTIONAL Installation:
Shower tray sound insulation set DWS
Model No: DWS: '.........'

Bath connection sound insulation tape WAS 70
Model No: WAS 70: '.........'

Shower tray anti-drumming set DW-ADS
Model No: DW-ADS: '.........'

Central support system MAS 5305: required for side lengths greater than or equal to 900 mm
Model No: 5305: '.........'

Shower surface frame FR 5300 FLEX (for -1 models)
Model No: 5300: '.........'

Sealing set FLEX
Model No: Sealing set FLEX: '.........'

System Installation Box S-IX
Model No: System Installation Box SIX: '.........'

Cut protection tape
Model No: Cut protection tape: '.........'

Installation system frame ESR Floor-level (for -1 models)
Model No: ESR FLOOR-LEVEL: '.........'

Shower surface frame FR 5300 FLEX PLUS (for -1 models)
Model No: 5300_PLUS: '.........'

Sealing set Floor-level
Model No: Sealing set Floor-level: '.........'

Bath installation tape WES 130: For sound insulation and separation between the product's bottom edge and the brickwork
Model No: WES 130: '.........'

OPTIONAL Waste/overflow technology:
Waste fitting KA 90 horizontal: Chrome waste cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled waste cover for KA 90
Model No: 4103: '.........'

Waste fitting KA 90 flat: Chrome waste cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled waste cover for KA 90
Model No: 4104: '.........'

Waste fitting KA 90 vertical: Chrome waste cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled waste cover for KA 90
Model No: 4105: '.........'

Waste cover KA 90: in addition to fittings 4103, 4104, 4105
Model No: Waste cover KA 90: '.........'
Alpine white: '...........'
Sanitary colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

Shower surface colours:
Alpine white: '...........'
Sanitary colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

OPTIONAL Surfaces:
Anti-slip surface KALDEWEI SECURE PLUS Antislip: '...........'
Anti-slip surface Antislip enamelling: '...........'
Anti-slip surface Full anti-slip enamelling: '...........'
Easy-care PERL-EFFECT: '...........'
Virtually invisible anti-slip on the standing surface INVISIBLE GRIP: '...........'
Note: Anti-slip surfaces cannot be combined with Pearl effect

According to EU Construction Products Regulation (CPR):
CE 15 KBW001 PH/marked according to
DIN EN 14516 - CL1+CL2
Certified surface:
Scratch and impact resistant, chemical resistant,
heat resistant, UV resistant, dimensionally stable,
easy-care and hygienic.

Safety technical examination:
TÜV Rheinland confirms that KALDEWEI's
Antislip/Full Antislip enamelling has
slip resistance according to assessment group B
for wet barefoot areas (DIN 51097) and
according to assessment group R10 for anti-slip
properties in workrooms and work areas
with increased slip risk (DIN 51130).

Attention: Item number (GTIN) refers to the standard white variant from the product family.
