KALDEWEI Shower Tray SUPERPLAN CLASSIC 80x100 Alpine White

KALDEWEI SUPERPLAN CLASSIC shower surface, 800x1000x32 mm, Model No: 398-1

Product description:
Floor-level shower surface with corner drain and circumferential embossing.

EU TAXONOMY READY through the official publication of EPDs

Here you can find the current Environmental Product Declaration (EPD):
https://www.kaldewei.de/unternehmen/nachhaltigkeit/epd

Steel enamel products stand for sustainability and are 100% recyclable.

The standard white version of this product
is officially Cradle to Cradle certified® in Silver.

Model: SUPERPLAN CLASSIC
Model No: 398-1
External length (mm): 800
External width (mm): 1000
Rim height (mm): 32
Depth (mm): 25
Material: KALDEWEI Steel Enamel
Manufacturer: KALDEWEI

Product specification:
Shower tray shape: Rectangle
Installation: Suitable for floor-level installation
Warranty: 30 years according to warranty certificate
MADE IN GERMANY
Drain hole (mm): 90
Drain position: Corner drain
Earthing lug for potential equalisation.
Weight (kg): 20.80
CO2 footprint (kg): 27.25

OPTIONAL Installation:
Shower tray sound insulation set DWS
Model No: DWS: '.........'

Bath connection sound insulation tape WAS 70
Model No: WAS 70: '.........'

Shower tray anti-drumming set DW-ADS
Model No: DW-ADS: '.........'

Center support system MAS 5305: required for side lengths greater than or equal to 900 mm
Model No: 5305: '.........'

Shower surface foot frame FR 5300 FLEX (for -1 models)
Model No: 5300: '.........'

Sealing set FLEX
Model No: Sealing set FLEX: '.........'

Shower surface foot frame FR 5300 FLEX PLUS (for -1 models)
Model No: 5300_PLUS: '.........'

System installation box S-IX
Model No: System installation box SIX: '.........'

Cut protection tape
Model No: Cut protection tape: '.........'

Installation system frame ESR Floor-level (for -1 models)
Model No: ESR BODENEBEN: '.........'

Sealing set Floor-level
Model No: Sealing set Bodeneben: '.........'

Bath installation tape WES 130: For sound insulation and separation between product bottom edge and brickwork
Model No: WES 130: '.........'

OPTIONAL Inlet/outlet technology:
Waste fitting KA 90 flat: Chrome waste cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enameled waste cover for KA 90
Model No: 4104: '.........'

Waste fitting KA 90 vertical: Chrome waste cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enameled waste cover for KA 90
Model No: 4105: '.........'

Waste fitting KA 90 horizontal: Chrome waste cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enameled waste cover for KA 90
Model No: 4103: '.........'

Waste cover KA 90: in addition to fittings 4103, 4104, 4105
Model No: Waste cover KA 90: '.........'
Alpine white: '...........'
Sanitary colors: '...........'
COORDINATED COLOURS COLLECTION: '...........'

Shower surface colors:
Alpine white: '...........'
Sanitary colors: '...........'
COORDINATED COLOURS COLLECTION: '...........'

OPTIONAL Surfaces:
Non-slip surface full anti-slip enameling: '...........'
Non-slip surface anti-slip enameling: '...........'
Non-slip surface KALDEWEI SECURE PLUS Antislip: '...........'
Easy-care PERL-EFFECT: '...........'
Almost invisible anti-slip on the standing area INVISIBLE GRIP: '...........'
Note: Non-slip surfaces cannot be combined with Pearl effect

According to EU Construction Products Regulation (CPR):
CE 15 KBW001 PH/marked according to
DIN EN 14516 - CL1+CL2
Certified surface:
Scratch and impact resistant, chemical resistant,
heat resistant, UV resistant, dimensionally stable,
easy-care and hygienic.

Safety technical examination:
TÜV Rheinland confirms that the
Antislip/Full Antislip enamelling from KALDEWEI has a
slip resistance according to assessment group B
for wet barefoot areas (DIN 51097) and
according to assessment group R10 for non-slip
properties in workrooms and work areas
with increased risk of slipping (DIN 51130).

Attention: Item number (GTIN) refers to the standard white version from the product family.
