KALDEWEI SUPERPLAN Shower Tray 90x90 Alpine White Shower Tray Support

KALDEWEI SUPERPLAN with Shower Tray Support, 900x900x32 mm, Model No: 1848-2

Product Description:
Floor-level shower surface with corner drain and accessible from 2 sides without edges

EU TAXONOMY READY through the official publication of EPDs

You can find the current Environmental Product Declaration (EPD) here:
https://www.kaldewei.de/unternehmen/nachhaltigkeit/epd

Steel enamel products stand for sustainability and are 100% recyclable.

The standard white variant of this product
is officially Cradle to Cradle certified® in Silver.

Model: SUPERPLAN with Shower Tray Support
Model No: 1848-2
Outer Length (mm): 900
Outer Width (mm): 900
Edge Height (mm): 32
Depth (mm): 25
Material: KALDEWEI Steel Enamel
Manufacturer: KALDEWEI

Product Specification:
Shower Surface Shape: Square
Installation: Raised installation
Warranty: 30 years according to warranty certificate
MADE IN GERMANY
Drain Hole (mm): 90
Drain Position: Corner drain
Earthing lug for potential equalisation.
Weight (kg): 22.00

OPTIONAL Installation:
System Installation Box S-IX
Model No: System Installation Box SIX: '.........'

Sealing Set Floor-level
Model No: Sealing Set Floor-level: '.........'

Tub Installation Tape WES 130: For sound insulation and separation between the bottom edge of the product and the masonry
Model No: WES 130: '.........'

Sealing Set FLEX
Model No: Sealing Set FLEX: '.........'

OPTIONAL Inlet/Outlet Technology:
Drain Cover KA 90: supplementary to sets 4103, 4104, 4105
Model No: Drain Cover KA 90: '.........'
Alpine White: '...........'
Sanitary Colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

Drain Fitting KA 90 flat: Chrome drain cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled drain cover for KA 90
Model No: 4104: '.........'

Drain Fitting KA 90 vertical: Chrome drain cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled drain cover for KA 90
Model No: 4105: '.........'

Drain Fitting KA 90 horizontal: Chrome drain cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled drain cover for KA 90
Model No: 4103: '.........'

Shower Surface Colours:
Alpine White: '...........'
Sanitary Colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

OPTIONAL Surfaces:
Easy-care PEARL EFFECT: '...........'
Slip-resistant surface KALDEWEI SECURE PLUS Antislip: '...........'
Virtually invisible slip resistance on the standing surface INVISIBLE GRIP: '...........'
Note: Slip-resistant surfaces cannot be combined with the Pearl Effect.

According to EU Construction Products Regulation (CPR):
CE 15 KBW001 PH/marked according to
DIN EN 14516 - CL1+CL2
Certified surface:
Scratch and impact resistant, chemical resistant,
heat resistant, UV resistant, dimensionally stable,
easy to clean and hygienic.

Safety Technical Inspection:
TÜV Rheinland confirms that KALDEWEI's
Antislip/Full Antislip enamelling has a
slip resistance according to assessment group B
for wet barefoot areas (DIN 51097) and
according to assessment group R10 for slip-resistant
properties in workrooms and work areas
with increased risk of slipping (DIN 51130).

Attention: Article number (GTIN) refers to the standard white variant from the product family.
