KALDEWEI CAYONOPLAN Shower Tray 100x160 Alpine White Full Anti-Slip

KALDEWEI CAYONOPLAN Shower Surface, 1000x1600x40 mm, Model No: 2230-1

Product description:
Floor-level shower surface with all-round rim and side waste outlet.

EU TAXONOMY READY through the official publication of EPDs

You can find the current Environmental Product Declaration (EPD) here:
https://www.kaldewei.de/unternehmen/nachhaltigkeit/epd

Steel enamel products stand for sustainability and are 100% circular.

The standard white version of this product
is officially Cradle to Cradle certified® in Silver.

Model: CAYONOPLAN
Model No: 2230-1
Outer length (mm): 1000
Outer width (mm): 1600
Rim height (mm): 40
Depth (mm): 25
Material: KALDEWEI steel enamel
Manufacturer: KALDEWEI

Product specification:
Shower surface shape: Rectangle
Installation: Suitable for floor-level installation
Warranty: 30 years according to warranty certificate
MADE IN GERMANY
Waste hole (mm): 90
Waste position: side, central
Earthing lug for potential equalisation.
Weight (kg): 42.40
CO2 footprint (kg): 53.99

OPTIONAL Installation:
Shower tray sound insulation set DWS
Model No: DWS: '.........'

Bathtub connection sound insulation tape WAS 70
Model No: WAS 70: '.........'

Shower tray anti-drumming set DW-ADS
Model No: DW-ADS: '.........'

Centre support system MAS 5305: required for side lengths greater than or equal to 900 mm
Model No: 5305: '.........'

Sealing set FLEX
Model No: Sealing set FLEX: '.........'

Sealing set Floor-level
Model No: Sealing set Floor-level: '.........'

System-Installation-Box S-IX
Model No: System-Installation-Box SIX: '.........'

Bathtub installation tape WES 130: For sound insulation and separation between product bottom edge and masonry
Model No: WES 130: '.........'

Shower surface foot frame FR 5300 FLEX (for -1 models)
Model No: 5300: '.........'

Cut protection tape
Model No: Cut protection tape: '.........'

Installation system frame ESR Floor-level (for -1 models)
Model No: ESR FLOOR-LEVEL: '.........'

OPTIONAL Inlet/Waste Technology:
Waste fitting KA 90 flat: chrome waste cover, hair trap included in delivery.
Universally applicable for FR and ESR.
Optional accessory: enamelled waste cover for KA 90
Model No: 4104: '.........'

Waste fitting KA 90 vertical: chrome waste cover, hair trap included in delivery.
Universally applicable for FR and ESR.
Optional accessory: enamelled waste cover for KA 90
Model No: 4105: '.........'

Waste fitting KA 90 horizontal: chrome waste cover, hair trap included in delivery.
Universally applicable for FR and ESR.
Optional accessory: enamelled waste cover for KA 90
Model No: 4103: '.........'

Waste cover KA 90: in addition to fittings 4103, 4104, 4105
Model No: Waste cover KA 90: '.........'
Alpine white: '...........'
Sanitary colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

Shower surface colours:
Alpine white: '...........'
Sanitary colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

OPTIONAL Surfaces:
Anti-slip surface Anti-slip enamelling: '...........'
Anti-slip surface Full anti-slip enamelling: '...........'
Easy-care PEARL-EFFECT: '...........'
Anti-slip surface KALDEWEI SECURE PLUS Anti-slip: '...........'
Almost invisible anti-slip on the standing surface INVISIBLE GRIP: '...........'
Note: Anti-slip surfaces cannot be combined with Pearl-Effect

According to EU Construction Products Regulation (CPR):
CE 15 KBW001 PH/marked according to
DIN EN 14516 - CL1+CL2
Certified surface:
Scratch and impact resistant, chemical resistant,
heat resistant, UV resistant, dimensionally stable,
easy to clean and hygienic.

Safety technical examination:
TÜV Rheinland confirms that
KALDEWEI's Antislip/Full antislip enamelling has
slip resistance according to assessment group B
for wet barefoot areas (DIN 51097) and
according to assessment group R10 for anti-slip
properties in work areas and workplaces
with increased risk of slipping (DIN 51130).

Attention: Item number (GTIN) refers to the standard white version from the product family.
