HA Washbasin Single-Lever Mixer HANSAPRIMO 4940 chrome

GENERAL ATTRIBUTES: • Product group: Basin mixer • Installation type: Deck-mounted • Technical feature: Single-lever mixer • Finish: Chrome PRODUCT FEATURES: • Aerator type: PCA® constant flow rate independent of pressure • Connection: Connection via flexible pressure hoses • Installation: 1-hole • Handle/Control type: Single lever handle/grip, Handle with H+C marking • Spout type: Fixed spout • Extension: Pop-up waste with pull rod • Temperature settings: Temperature limiter, Adjustable hot water stop (included in scope of delivery) • Mechanical parts: ø 3.5 classic control cartridge with ceramic discs for water volume and temperature control • Special features: Faucet body made of dezincification-resistant brass (DZR), Rapid installation system FLOW PROPERTIES: • Flow rate at 300 kPa (flow limiter): 6.00 l/min REGULATIONS / STANDARDS: • EN Standard: EN 817 • Noise class: I (ISO 3822) APPROVALS: • DVGW: NW-6506CN0242 • KIWA: K6116/08 • ABP: P-IX 38251/IA TECHNICAL SPECIFICATIONS: • DN size: DN15 • Spout reach: 107 mm • Material: Brass • Hot water supply: max. +70C • Working pressure: 50 - 1000 kPa • Connection size: G3/8 • Backflow prevention (EN1717): AA LOGISTICS: • Gross weight: 1.601 kg • Packaging dimensions: 542 x 196 x 77
